Squeegee-System

• AC-Servo-drive
• high-precision-spindle-drive
• 4-Cylinder POWER-Squeegee-System
• Print/Floodbars with mecanical way-adjustment for precise hight-leveling
• Comfort-liftable print-cylinders

Supporting-arms/pallets

• With fast-snap tensioning-system
• Pallets slideable in lengthwise direction +/- 10 cm

Pallet-drive

• Precise gear-drive, frequency controlled AC-Servo-motor

Flock-System

• high voltage from 10 - 80 kV adjustable
• with ground surveillance
• digital kV- and uA-measuring devices
• automatic high voltage discharge
• dosing time and flock time adjustable

Central Main-Control with SMART- touch-screen Monitor

• with Siemens-standard-modules,
• microprocessor with diagnostic programm - easy to operate –
• control-keypads at every print station for fast set-up START, STOP, LIFT-UP/DOWN, Squeegee-movement Squeegee-stroke-speed individual adjustable
• prepared for permanent-spray-system
• central electronic off-contact adjustable on the touch-screen

Printing programmes

• 6-standard print programs + high density+cool-stop
• + sampling-start up - finishing programs+double-index+Multilap-program
• cleaning-program: in-between pallet-stop, left / right, free wheel-mode
